贴片电感的体积:0201 0402 0603 0805 1206 1210 1808 1812 1825 2220 2225,应于自动贴装的高尺寸精度绕线电感器;具有优良的Q值和高可靠性;
品牌: TDK
型号: NLCV32T-101K-PF
封装: 1210
规格: 100uH ±10% 120mA 3.7Ω1210
序号 No. | 部位 Component | 材料 Material | |
1 | 瓷体 Body |
铁氧体电感:镍铜锌体系Ni-Cu-Zn 甚高频电感:陶瓷体系AlzO3 |
|
2 | 内电极 Inner electrode | 纯银 Ag | |
3 |
端电极 Terminal electrode |
银层 Ag layer | 银 Ag |
Ni/Sn 镀层Ni/Sn plating | 镍层-锡层 Ni-Sn |
型号 Size | L | W | T | a |
100505 | 1.0士0.15 (0.040士0.006) | 0.5士0.15 (0.020士0.006) | 0.5士0.15(0.020士0.006) | 0.25士0.1(0.010+0.004) |
160808 | 1.6士0.20 (0.063土0.008) | 0.8士0.20 (0.031士0.008) | 0.8士0.20 (0.031土0.008) | 0.3土0.2(0.01土0.008) |
201209 | 2.0士0.20 (0.079士0.008) | 1.2士0.20 (0.047士0.008) | 0.9士0.20 (0.035士0.008) | 0.5士0.3(0.020土0.012) |
201212 | 2.0士0.20 (0.079士0.008) | 1.2士0.20 (0.047士0.008) | 1.2士0.20 (0.047士0.008) | 0.5士0.3(0.020士0.012) |
252009 | 2.5土0.20 (0.098土0.008) | 2.0士0.20 (0.079士0.008) | 0.9士0.20 (0.035士0.008) | 0.5士0.3(0.020士0.012) |
321609 | 3.2士0.20 (0.126士0.008) | 1.6士0.20 (0.063±0.008) | 0.9士0.20 (0.035士0.008) | 0.5士0.3(0.020士0.012) |
321611 | 3.2士0.20 (0.126士0.008) | 1.6士0.20 (0.063±0.008) | 1.1土0.20 (0.043士0.008) | 0.5士0.3(0.020士0.012) |
322513 | 3.2士0.20 (0.126士0.008) | 2.5土0.20 (0.098土0.008) | 1.3土0.20 (0.051士0.008) | 0.5土0.3(0.020士0.012) |
451616 | 4.5士0.20 (0.180士0.008) | 1.6±0.20 (0.063士0.008) | 1.6士0.20 (0.063士0.008) | 0.5士0.3(0.020士0.012) |
453215 | 4.5士0.20 (0.180士0.008) | 3.2士0.20 (0.126土0.008) | 1.5士0.20 (0.060士0.008) | 0.5士0.3(0.020土0.012) |
